Power Generation – FAQs (Frequently Asked Questions)

Many of our existing customers and / or prospective buyers rely upon ESL to provide them with accurate and informative answers to their electrical, engine, and generator related questions. This results in numerous questions every day, some of which are as under:

The primary difference between kW (kilowatt) and kVA (kilovolt-ampere) is the power factor. kW is the unit of real power and kVA is a unit of apparent power (or real power plus re-active power). The power factor, unless it is defined and known, is therefore an approximate value (typically 0.8), and the kVA value will always be higher than the value for kW.

In relation to industrial and commercial generators, kW is most commonly used when referring to generators in the United States, and a few other countries that use 60 Hz, while the majority of the rest of the world typically uses kVA as the primary value when referencing generator sets.

To expand on it a bit more, the kW rating is essentially the resulting power output a generator can supply based on the horsepower of an engine. kW is figured by the horsepower rating of the engine times 0.746.

For example if you have a 500 horsepower engine it has a kW rating of 373. The kilovolt-amperes (kVa) are the generator end capacity. Generator sets are usually shown with both ratings. To determine the kW and kVa ratio the formula below is used.
8 (pf) x 625 (kVa) = 500 kW

The power factor (pf) is typically defined as the ratio between kilowatts (kW) and kilovolt amps (kVa) that is drawn from an electrical load, as was discussed in the question above in more detail. It is determined by the generators connected load. The pf on the nameplate of a generator relates the kVa to the kW rating (see formula above). Generators with higher power factors transfer energy to the connected load more efficiently, while generators with a lower power factor are not as efficient and result in increased power costs. The standard power factor for a three phase generator is 0.8.

Standby power generators are most often used in emergency situations, such as during a power outage. It is ideal for applications that have another reliable continuous power source like utility power. Its recommended usage is most often only for the duration of a power outage and regular testing and maintenance.

Prime power ratings can be defined as having an “unlimited run time”, or essentially a generator that will be used as a primary power source and not just for standby or backup power. A prime power rated generator can supply power in a situation where there is no utility source, as is often the case in industrial applications like mining or oil & gas operations located in remote areas where the grid is not accessible.

Continuous power is similar to prime power but has a base load rating. It can supply power continuously to a constant load, but does not have the ability to handle overload conditions or work as well with variable loads. The main difference between a prime and continuous rating is that prime power gensets are set to have maximum power available at a variable load for an unlimited number of hours, and they generally include a 10% or so overload capability for short durations.

Generator ends are designed to be either reconnectable or non-reconnectable. If a generator is listed as reconnectable, the voltage can be changed, consequently if it is non-reconnectable, the voltage is not changeable. 12-lead reconnectable generator ends can be changed between three and single phase voltages; however, keep in mind that a voltage change from three phase to single phase will decrease the power output of the machine. 10-lead reconnectable can be converted to three phase voltages but not to single phase.

An automatic transfer switch (ATS) transfers power from a standard source, like utility, to emergency power, such as a generator, when the standard source fails. An ATS senses the power interruption on the line and in turn signals the engine panel to start. When the standard source is restored to normal power the ATS transfers power back to the standard source and shuts the generator down. Automatic Transfer Switches are often used in high availability environments such as data centers, manufacturing plans, telecommunication networks and so forth.

Generator sets can be paralleled for either redundancy or capacity requirements. Paralleling generators allows you to electrically join them to combine their power output. Paralleling identical generators will not be problematic but some extensive thought should go into the overall design based on the primary purpose of your system. If you are trying to parallel unlike generators the design and installation can be more complex and you must keep in mind the effects of engine configuration, generator design, and regulator design, just to name a few. For paralleling of generators of any make, model and manufacturer, please contact ESL at customercare@eslpk.com

In general, most commercial generators can be converted from 60 Hz to 50 Hz. The general rule of thumb is 60 Hz machines run at of 1800 Rpm and 50 Hz generators run at 1500 Rpm. With most generators changing the frequency will only require turning down the engine’s rpm. In some cases, parts may have to be replaced or further modifications made. Larger machines or machines already set at low Rpm are different and should always be evaluated on a case to case basis. It is advisable to consult a power generation expert before attempting this conversion.

Getting a generator that can handle all your power generation needs is one of the most critical aspects of the purchasing decision. Whether you are interested in prime or standby power, if your new generator can’t meet your specific requirements then it simply won’t be doing anyone any good because it can put undue stress on the unit and even damage some of the devices connected to it. Determining exactly what size of generator to get is often very difficult and involves a number of factors and considerations like environmental conditions, size and type of loads, etc.
It is always better to delve deep into your power generation requirements before making a choice. You can do this the following ways:

  1. Make a list of the items that need to be powered by the generator.
  2. Make a note of the starting and running wattage of the respective items.
  3. Calculate the total power requirements in KVA or KW.

Getting the right starting and running wattage of the devices you intend to power
is crucial for calculating the accurate power requirements. Normally, you will find these in the identification plate or the owner’s manual in the buyer’s kit of each respective device, tool, appliance, or other electrical equipment.

Ampere-Watt Conversion- You may often find power requirements of tools stated in amperes. In order to convert the power requirement of a tool from ampere to watts, follow these calculations.

For resistive load: Wattage = amperes x volts
For reactive load: Wattage = (amperes x volts) x load factor

For further assistance, seek help from our technical team.

There are some highly critical applications such as data centers, process industries, hospitals and operation theaters etc where disruption in electrical power is neither affordable nor permissible. In such applications either large UPS systems or additional devices are used on either side of the power outage which ensure that gensets are momentarily paralleled with utility while switching load from the generator to the mains or vice versa. This ensures that operations are not hurt or hindered in any way and continuous, uninterrupted supply of power is available at all times. For more details and / or incorporation of bump less transfer features in existing system, please consult ESL at customercare@eslpk.com

Load management is prioritization of loads in order of their critical nature and adding / shedding of the same in view of the available power from the generator(s). Demand management is automatic switching ON / OFF gensets in view of the load that is to be supported at any given point of time. For more details and / or incorporation of load and demand management panels in existing system, please consult ESL at customercare@eslpk.com

If you have any other question, please ask us at customercare@eslpk.com
